ASROCK H810M-XGEN5WIFI LGA1851 Micro ATX DDR5 Budget Build
ASROCK

ASROCK H810M-XGEN5WIFI LGA1851 Micro ATX DDR5 Budget Build

  • Processor manufacturerIntel
  • Maximum internal memory128 GB
  • Supported storage drive interfacesSATA III, M.2
  • Top Wi-Fi standardWi-Fi 6 (802.11ax)
  • Audio chipRealtek ALC897
  • Windows operating systems supportedWindows 11 x64
  • Width244 mm
  • HDMI ports quantity1

The ASROCK H810M-XGEN5WIFI is a compact micro ATX motherboard built for Intel LGA 1851 processors, delivering real value for budget-conscious builders who don't want to compromise on connectivity. WiFi and DDR5 support on a sub-flagship chipset means you get modern features without the premium price tag.

  • Intel H810 chipset paired with LGA 1851 Socket V1 for current-gen Intel CPUs
  • DDR5-SDRAM support with 2 memory slots — future-proof your build without overspending
  • Built-in WiFi keeps cable clutter to a minimum in small builds
  • Single M.2 slot for fast NVMe storage in tight spaces

Description

Compact, Connected, DDR5-Ready

Ideal for compact PCs, office setups, or entry-level gaming builds where space and cost matter but you still want DDR5 performance and WiFi out of the box.

Specifications

General

BrandASROCK
HDCPYes
Line-inYes
BIOS typeUEFI AMI
HDCP version2.3
Component forPC
BIOS memory size256
Unbuffered memoryYes
ECC сompatibilityNon-ECC
RGB LED pin headerYes
Number of memory slots2
Motherboard form factormicro ATX
Number of M.2 (M) slots1
PCI Express x1 (Gen 4.x) slots1
PCI Express x16 (Gen 5.x) slots1
Warranty36 months
EAN4711581493834

Processor

Processor manufacturerIntel
Motherboard chipsetIntel H810
Processor socketLGA 1851 (Socket V1)
CPU fan connectorYes
Motherboard chipset familyIntel
Compatible processor seriesIntel Core Ultra (Series 2)
Number of CPU fan connectors1

Memory

Maximum internal memory128 GB
Memory channelsDual-channel
Memory slots typeDIMM

Storage

Supported storage drive interfacesSATA III, M.2

Audio

Audio chipRealtek ALC897
Microphone inYes
Audio output channels7.1
Front panel audio connectorYes

Ports

HDMI ports quantity1
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
TPM connectorYes
LAN controllerDragon RTL8125BG
USB 2.0 connectors1
DisplayPort version1.4
DisplayPorts quantity1
Ethernet interface type2.5 Gigabit Ethernet
EPS power connector (8-pin)Yes
ATX Power connector (24-pin)Yes
Number of SATA III connectors4
Number of chassis fan connectors1
USB 3.2 Gen 1 (3.1 Gen 1) connectors2

Connectivity

Wi-FiYes
Wi-Fi standards802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
BluetoothYes
Bluetooth version5.3
Antenna includedYes

Software & security

Windows operating systems supportedWindows 11 x64

Features

Cables includedSATA
Supported memory typesDDR5-SDRAM

Dimensions & weight

Width244 mm
Depth193 mm
