NEOMOUNTS

MONITOR ACC SCREEN &DESK MOUNT/FPMA-D550NOTEBOOK NEOMOUNTS

  • Panel mounting interface100 x 100/75 x 75
  • Maximum weight capacity8
  • Angle of rotation360
  • Depth520 mm

Description

The Neomounts desk mount, model FPMA-D550NOTEBOOK is a tilt-, swivel and rotatable desk mount for flat screens up to 32" notebooks up to 15,6". This mount is a great choice for space saving placement on desks using a desk clamp or grommet.

Neomounts' unique tilt (+45°/-45°), swivel (180°) and rotate (360°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 0 to 44 centimetres. Depth adjustable from 4 to 52 centimetres. A unique cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.

Neomounts FPMA-D550NOTEBOOK has three pivot points and is suitable for screens up to 32". The weight capacity of this product is 8 kg for the screen and 4,5 kg for the notebook. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.

By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.

All installation material is included with the product.

Specifications

General

BrandNEOMOUNTS
Product colourBlack
Housing materialSteel
MountingClamp/Grommet
RotatingYes
SwivellingYes
Swivel angle180
Mounting typeDesk
Tilt adjustmentYes
Cable managementYes
Tilt angle range0 - 90
Height adjustmentYes
Maximum VESA mount100 x 100
Minimum VESA mount75 x 75
Swivel angle range0 - 180
Desk thickness (max)88
Desk thickness (min)10
Depth adjustment range40 - 520
Height adjustment typeManual
Number of pivot points3
Height adjustment range0 - 440
Products per pallet (EU)55
Master (outer) case width310
Master (outer) case height480
Master (outer) case length370
Master (outer) case net weight5200
Master (outer) case gross weight6300
Products per master (outer) case3
Warranty60 months
EAN8717371446413

Display

Panel mounting interface100 x 100/75 x 75
Maximum screen size32
Minimum screen size10
Number of displays supported1
Maximum weight capacity (per display)8

Storage

Maximum weight capacity8

Performance & capacities

Angle of rotation360

Dimensions & weight

Depth520 mm
Height548 mm
Weight5.67 kg
