TP-Link LS105LP network switch, 5 ports, 4 with PoE, 41 W

Switching capacity1
Power consumption (max)46.45 W
Operating temperature (T-T)0 – 40 °C
Switch typeUnmanaged
Width100 mm
Copper ethernet cabling technology100BASE-TX/10BASE-T
Package typeBox

The TP-Link LS105LP is a LiteWave unmanaged switch with five Fast Ethernet ports (10/100 Mbit/s), four of which supply PoE (802.3af). The total PoE budget is 41 W, with up to 15.4 W per port, enough for an IP camera, access point or IP phone. The fanless metal case runs silently.

Type. unmanaged
Ports. 5 × 10/100 Mbit/s
PoE ports. 4 × PoE (802.3af)
Total PoE budget. 41 W
PoE per port. 15.4 W
Mounting. desktop or wall
Dimensions (W × D × H). 100 × 98 × 25 mm
Colour. black

Description

The maker highlights: Extend Mode carries PoE up to 250 m, and PoE Auto Recovery reboots a device that stops responding.

Specifications

General

Brand	TP-LINK
Model name	LS105LP
Product colour	Black
Fanless	Yes
User guide	Yes
Number of fans	0
Wall mountable	Yes
Forwarding rate	0.744
Auto-negotiation	Yes
MAC address table	2000
Store-and-forward	Yes
Operating relative humidity (H-H)	10 - 90
Warranty	60 months
EAN	4895252504583

Storage

Switching capacity	1
Storage temperature (T-T)	-40 - 70
Storage relative humidity (H-H)	5 - 90

Ports

Power over Ethernet (PoE)	Yes
Copper ethernet cabling technology	100BASE-TX/10BASE-T
Power over Ethernet (PoE) ports quantity	4
Power over Ethernet (PoE) power per port	15.4
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	5

Connectivity

Networking standards	IEEE 802.3af/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x

Keyboard & controls

Switch type	Unmanaged

Battery & power

Power consumption (max)	46.45 W
AC input voltage	220 V
AC input frequency	50 Hz
Power source	DC/PoE
Input current	0.81
DC input voltage	53.5
Power supply included	Yes

Performance & capacities

Operating temperature (T-T)	0 – 40 °C
Heat dissipation	157.93

Features

LED indicators	Yes
10G support	No
Package type	Box
Auto MDI/MDI-X	Yes
Flow control support	Yes
Jumbo frames support	Yes
Cable types supported	Cat3/Cat4/Cat5/Cat5e
Quality of Service (QoS) support	Yes
