Reliable networking for small offices and workgroups
Ideal if you're setting up a small office network, adding surveillance cameras, or expanding coverage with wireless access points and want one less thing to plug in.
TP-LINK
TP-LINK TL-SG105PE 5-Port Gigabit PoE Switch
- Switching capacity10
- Power consumption (max)75.16 W
- Operating temperature (T-T)0 – 40 °C
- Switch typeManaged
- Width99.8 mm
- Virtual LAN featuresPort-based VLAN/Tagged VLAN
- LED indicatorsActivity/Link/PoE/Power/Speed/Status
- Four PoE-enabled ports let you power IP cameras, wireless access points and VoIP phones directly from the switch
- All five ports run at Gigabit speeds (up to 1000 Mbps), so your data moves fast
- Desktop form factor takes minimal space on a shelf or desk – no rack mounting needed
- Managed operation gives you visibility and control over your network traffic
Description
Specifications
General
| Brand | TP-LINK |
|---|---|
| Model name | 5-Port Gigabit Easy Smart PoE Switch with 4-Port PoE+ |
| Product colour | Black |
| Fanless | Yes |
| User guide | Yes |
| Jumbo frames | 16000 |
| IGMP snooping | Yes |
| Rack mounting | No |
| Rate limiting | Yes |
| Forwarding rate | 7.44 |
| Number of VLANs | 4000 |
| Auto-negotiation | Yes |
| Link aggregation | Yes |
| Number of queues | 4 |
| MAC address table | 2000 |
| Store-and-forward | Yes |
| Packet buffer memory | 1 |
| Web-based management | Yes |
| Broadcast storm control | Yes |
| Operating relative humidity (H-H) | 10 - 90 |
| Warranty | 60 months |
| EAN | 6935364052744 |
Storage
| Switching capacity | 10 |
|---|---|
| Storage temperature (T-T) | -40 - 70 |
| Storage relative humidity (H-H) | 5 - 95 |
Ports
| Power over Ethernet (PoE) | Yes |
|---|---|
| Port mirroring | Yes |
| Virtual LAN features | Port-based VLAN/Tagged VLAN |
| Copper ethernet cabling technology | 1000BASE-T/100BASE-FX/100BASE-TX/10BASE-T |
| Total Power over Ethernet (PoE) budget | 65 |
| Gigabit Ethernet (copper) ports quantity | 5 |
| Power over Ethernet (PoE) power per port | 30 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
Connectivity
| Networking standards | IEEE 802.1p/IEEE 802.1Q/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x |
|---|
Keyboard & controls
| Switch type | Managed |
|---|---|
| Switch layer | L2 |
Battery & power
| Power consumption (max) | 75.16 W |
|---|---|
| Input voltage | 53.5 V |
| Power source | DC |
| Input current | 1.31 |
| Power supply included | Yes |
Performance & capacities
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| Heat dissipation | 256.3 |
Features
| LED indicators | Activity/Link/PoE/Power/Speed/Status |
|---|---|
| 10G support | No |
| VLAN support | Yes |
| Auto MDI/MDI-X | Yes |
| Loop protection | Yes |
| Flow control support | Yes |
| Jumbo frames support | Yes |
| Cable types supported | Cat3/Cat4/Cat5/Cat5e/Cat6 |
| Quality of Service (QoS) support | Yes |
Dimensions & weight
| Width | 99.8 mm |
|---|---|
| Depth | 98 mm |
| Height | 25 mm |
