Plug in, power up, get on with it
Ideal for small offices, retail sites and expanding home networks where you need straightforward switching with power delivery built in. Grab one if you're adding networked devices or upgrading from an older switch.
TP-LINK
TP-LINK TL-SG1210P Gigabit Switch PoE+ 9-Port
- Switching capacity20
- Power consumption (typical)7.11 W
- Operating temperature (T-T)0 – 50 °C
- Switch typeUnmanaged
- Width209 mm
- Fiber ethernet cabling technology1000BASE-X
- Cables includedAC
- 9 gigabit ethernet ports handle full 1000 Mbps speeds across your network
- PoE+ on 8 ports powers compatible devices while they connect—no separate power supplies needed
- 1 SFP slot adds fibre uplink flexibility for longer distances or existing backbone gear
- Unmanaged design means zero configuration—just mount and forget
Description
Specifications
General
| Brand | TP-LINK |
|---|---|
| Model name | TL-SG1210P |
| Product colour | Grey |
| Housing material | Metal |
| Manual | Yes |
| Fanless | Yes |
| Fiber type | Single-mode |
| User guide | Yes |
| IGMP snooping | Yes |
| Wall mountable | Yes |
| Auto-negotiation | Yes |
| MAC address table | 4000 |
| Quick start guide | Yes |
| Store-and-forward | Yes |
| SFP module slots quantity | 1 |
| Operating relative humidity (H-H) | 10 - 90 |
| Warranty | 60 months |
| EAN | 6935364052980 |
Storage
| Switching capacity | 20 |
|---|---|
| Storage temperature (T-T) | -40 - 70 |
| Storage relative humidity (H-H) | 5 - 90 |
Ports
| Power over Ethernet (PoE) | Yes |
|---|---|
| Fiber ethernet cabling technology | 1000BASE-X |
| Copper ethernet cabling technology | 1000BASE-T/100BASE-TX/10BASE-T |
| Total Power over Ethernet (PoE) budget | 63 |
| Gigabit Ethernet (copper) ports quantity | 9 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 9 |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
Connectivity
| Networking standards | IEEE 802.1p/IEEE 802.3af/IEEE 802.3at/IEEE 802.3x |
|---|
Keyboard & controls
| Switch type | Unmanaged |
|---|
Battery & power
| Power consumption (typical) | 7.11 W |
|---|---|
| Power consumption (max) | 78.13 W |
| Input current | 1.31 |
| DC input voltage | 53.5 |
| Power supply included | No |
Performance & capacities
| Operating temperature (T-T) | 0 – 50 °C |
|---|---|
| Heat dissipation | 266.42 |
Features
| Cables included | AC |
|---|---|
| LED indicators | Yes |
| 10G support | No |
| Auto MDI/MDI-X | Yes |
| MAC address auto-aging supported | Yes |
| Quality of Service (QoS) support | Yes |
| MAC address auto-learning supported | Yes |
Dimensions & weight
| Width | 209 mm |
|---|---|
| Depth | 126 mm |
| Height | 26 mm |
