TP-LINK Omada EAP650 2976 Mbps WiFi 6 Access Point
TP-LINK

TP-LINK Omada EAP650 2976 Mbps WiFi 6 Access Point

  • Storage temperature (T-T)-40 - 70
  • DC voltage range12
  • Operating temperature (T-T)0 – 40 °C
  • MIMO typeMulti User MIMO
  • Width160 mm
  • Ethernet LAN (RJ-45) ports1
  • Package typeBox

The TP-LINK Omada EAP650 is a ceiling or wall-mounted access point built for fast, reliable WiFi 6 coverage across homes and small offices. With speeds up to 2976 Mbps and Power over Ethernet support, you get simplified installation and strong performance without the price tag of enterprise gear.

  • WiFi 6 (802.11ax) delivers faster data rates and handles multiple devices smoothly
  • Single Gigabit Ethernet port with PoE support means one cable does the job—no separate power adapter needed
  • Flexible ceiling or wall mounting fits your space without fuss
  • Omada cloud management keeps your network organized and secure

Description

Built for speed and easy setup

Ideal if you're upgrading from older WiFi standards or need reliable coverage in a room or zone where your current router doesn't reach. A solid choice for anyone who values straightforward installation and real-world performance.

Specifications

General

BrandTP-LINK
Model nameEAP650
Product colourWhite
5 GHzYes
6 GHzNo
SeriesOmada
SyslogYes
2.4 GHzYes
PlacementCeiling, Wall
BeamFormingYes
Mounting kitYes
Rate limitingYes
Number of users250
Quick start guideYes
Firmware upgradeableYes
Web-based managementYes
Airtime Fairness (ATF)Yes
Spread spectrum methodOFDMA
Access Control List (ACL)Yes
Automatic channel scanningYes
Maximum data transfer rate2976
Automatic channel selectionYes
Operating relative humidity (H-H)10 - 90
Maximum data transfer rate (5 GHz)2402
Maximum data transfer rate (2.4 GHz)574
Warranty60 months
EAN4897098683545

Storage

Storage temperature (T-T)-40 - 70
Storage relative humidity (H-H)5 - 90

Ports

Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10/100/1000
DC-in jackYes
Power over Ethernet (PoE)Yes

Connectivity

Networking standardsIEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.1x/IEEE 802.3at
Security algorithmsSNMP/SNMPv2/SNMPv3/SSH/WPA2-Enterprise/WPA2-PSK/WPA3-Enterprise/WPA3-PSK/WPA-Enterprise/WPA-PSK
MIMOYes
MIMO typeMulti User MIMO
Antenna typeInternal
Band steeringYes
Frequency band2.4 - 5

Keyboard & controls

Reset buttonYes

Battery & power

DC voltage range12
Transmitting power (CE)<20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz, Band1 & Band2, EIRP) <30 dBm(5 GHz, Band3, EIRP)
Transmitting power (FCC)<25 dBm (2.4 GHz) <25 dBm (5 GHz)

Performance & capacities

Operating temperature (T-T)0 – 40 °C
Fit AP mode featuresMesh networking
MAC address filteringYes

Features

LED indicatorsYes
Package typeBox
VLAN supportYes
Cabling technology10/100/1000Base-T(X)
Flow control supportYes
Quality of Service (QoS) supportYes

Dimensions & weight

Width160 mm
Depth160 mm
Height33.6 mm
