TP-LINK Omada EAP653 WiFi 6 Access Point 2976 Mbps

  • Storage temperature (T-T)-40 - 70
  • DC voltage range12
  • Operating temperature (T-T)0 – 40 °C
  • Security algorithmsHTTPS/SNMP/SNMPv2/SNMPv3/SSH/WPA/WPA2/WPA3
  • Width160 mm
  • Ethernet LAN (RJ-45) ports1
  • Package typeBox

The TP-LINK Omada EAP653 is a WiFi 6 access point built for businesses that need reliable, fast coverage without the headache of complex setup. With 2976 Mbps total throughput and centralized cloud management via Omada SDN, you get enterprise-grade networking at a competitive price point.

  • WiFi 6 performance with automatic channel and power adjustment to cut interference across your network
  • Mesh-ready design — extend your signal wirelessly to difficult corners without extra cabling
  • Single PoE connection keeps installation clean and reduces wiring clutter
  • Mounts on ceiling or wall with a slim profile that fits modern office spaces

Description

Coverage and control, simplified

Ideal for growing businesses, hospitality venues, or anyone upgrading their wireless backbone and wanting one dashboard to manage it all.

Specifications

General

BrandTP-LINK
Model nameEAP653
Product colourWhite
5 GHzYes
6 GHzNo
SeriesOmada
SyslogYes
2.4 GHzYes
PlacementCeiling, Wall
BeamFormingYes
Mounting kitYes
Rate limitingYes
Number of users250
Quick start guideYes
Firmware upgradeableYes
Web-based managementYes
Airtime Fairness (ATF)Yes
Spread spectrum methodOFDMA
Automatic channel scanningYes
Maximum data transfer rate2976
Automatic channel selectionYes
Operating relative humidity (H-H)10 - 90
Maximum data transfer rate (5 GHz)2402
Maximum data transfer rate (2.4 GHz)574
Warranty60 months
EAN4897098685235

Storage

Storage temperature (T-T)-40 - 70
Storage relative humidity (H-H)5 - 90

Ports

Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10/100/1000
DC-in jackYes
Power over Ethernet (PoE)Yes

Connectivity

Networking standardsIEEE 802.11a/IEEE 802.11ac/IEEE 802.11b/IEEE 802.11g/IEEE 802.11h
Security algorithmsHTTPS/SNMP/SNMPv2/SNMPv3/SSH/WPA/WPA2/WPA3
MIMOYes
MIMO typeMulti User MIMO
Antenna typeInternal
Band steeringYes
Frequency band2.4 - 5

Keyboard & controls

Reset buttonYes

Battery & power

DC voltage range12
Transmitting power (CE)27
Transmitting power (FCC)22

Performance & capacities

Operating temperature (T-T)0 – 40 °C
Fit AP mode featuresMesh networking
MAC address filteringYes

Features

LED indicatorsYes
Package typeBox
VLAN supportYes
Cabling technology10/100/1000Base-T(X)
Flow control supportYes
Quality of Service (QoS) supportYes

Dimensions & weight

Width160 mm
Depth160 mm
Height33.6 mm
Product Net Weight0.5 kg
