Coverage and control, simplified
Ideal for growing businesses, hospitality venues, or anyone upgrading their wireless backbone and wanting one dashboard to manage it all.
Ideal for growing businesses, hospitality venues, or anyone upgrading their wireless backbone and wanting one dashboard to manage it all.
| Brand | TP-LINK |
|---|---|
| Model name | EAP653 |
| Product colour | White |
| 5 GHz | Yes |
| 6 GHz | No |
| Series | Omada |
| Syslog | Yes |
| 2.4 GHz | Yes |
| Placement | Ceiling, Wall |
| BeamForming | Yes |
| Mounting kit | Yes |
| Rate limiting | Yes |
| Number of users | 250 |
| Quick start guide | Yes |
| Firmware upgradeable | Yes |
| Web-based management | Yes |
| Airtime Fairness (ATF) | Yes |
| Spread spectrum method | OFDMA |
| Automatic channel scanning | Yes |
| Maximum data transfer rate | 2976 |
| Automatic channel selection | Yes |
| Operating relative humidity (H-H) | 10 - 90 |
| Maximum data transfer rate (5 GHz) | 2402 |
| Maximum data transfer rate (2.4 GHz) | 574 |
| Warranty | 60 months |
| EAN | 4897098685235 |
| Storage temperature (T-T) | -40 - 70 |
|---|---|
| Storage relative humidity (H-H) | 5 - 90 |
| Ethernet LAN (RJ-45) ports | 1 |
|---|---|
| Ethernet LAN data rates | 10/100/1000 |
| DC-in jack | Yes |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11b/IEEE 802.11g/IEEE 802.11h |
|---|---|
| Security algorithms | HTTPS/SNMP/SNMPv2/SNMPv3/SSH/WPA/WPA2/WPA3 |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Antenna type | Internal |
| Band steering | Yes |
| Frequency band | 2.4 - 5 |
| Reset button | Yes |
|---|
| DC voltage range | 12 |
|---|---|
| Transmitting power (CE) | 27 |
| Transmitting power (FCC) | 22 |
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| Fit AP mode features | Mesh networking |
| MAC address filtering | Yes |
| LED indicators | Yes |
|---|---|
| Package type | Box |
| VLAN support | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Flow control support | Yes |
| Quality of Service (QoS) support | Yes |
| Width | 160 mm |
|---|---|
| Depth | 160 mm |
| Height | 33.6 mm |
| Product Net Weight | 0.5 kg |
